Network Scan OpenVAS

What is a Network Vulnerability Scanner?

The network perimeter of a company is the "wall" that secures internal network assets from the outside world. Connecting from outside means accessing internal assets (e.g. a company's website). This way, the network perimeter exposes important network services such as FTP, VPN, DNS, HTTP, and more.

A Network Vulnerability Scanner maps all the services exposed on the network perimeter and checks for potential vulnerabilities.

Details about our scanner

The Light version of our Network Vulnerability Scanner performs a very fast security assessment with minimum interaction with the target system. It starts by running Nmap to detect open ports and services. Then, based on the results returned by Nmap, our network scanner interrogates a database with known vulnerabilities to check if the specific versions of the services are affected by any issues. Although this detection method is faster, it can return false positives because it relies only on the version reported by the services (which may be inaccurate).

The Full version of the Network Vulnerability Scanner uses a mix of custom Sniper modules for high risk vulnerabilities and the well-known OpenVAS (the most advanced open source vulnerability scanner) as a scanning engine. It actively detects thousands of vulnerabilities in network services such as SMTP, DNS, VPN, SSH, RDP, VNC, HTTP, and many more. OpenVAS does vulnerability detection by connecting to each network service and sending crafted packets to make them respond in certain ways. Depending on the response, the scanner reports the service as vulnerable or not.

We have pre-configured and fine-tuned OpenVAS on our servers and have also added a very simple interface on top of its complex functionalities. The engine is running in a distributed environment and it can perform multiple parallel scans.

The Sniper modules are custom vulnerability checks developed by our team. They are added on top of the standard OpenVAS scan in order to provide rapid detection of the most critical vulnerabilities from high-profile software. This is the complete list of Sniper detection modules currently available in our Network Scanner:

Software type	Vendor	Product	CVE	Vuln date	Codename
VPN Gateway	F5	BIG IP	CVE-2022-1388	May 2022	-
API Management	WSO2	Platform	CVE-2022-29464	Apr 2022	-
Web Framework	Apache	Struts	CVE-2021-31805	Apr 2022	S2-062
Web framework	Pivotal Software	Spring Framework	CVE-2022-22965	Mar 2022	-
Library	Pivotal Software	Spring Cloud Gateway	CVE-2022-22947	Mar 2022	-
Data store	Redis	Redis	CVE-2022-0543	Feb 2022	-
eCommerce	Adobe	Magento	CVE-2022-24086	Feb 2022	-
Monitoring solution	Zabbix	Zabbix	CVE-2022-23131	Jan 2022	-
Logging library	Apache	Log4j	CVE-2021-45046	Dec 2021	Log4Shell
Hypervisor	ManageEngine	Desktop Central	CVE-2021-44515	Dec 2021	-
Web Framework	Apache	Struts	CVE-2021-44228	Dec 2021	Log4Shell
Webserver	Apache	Tomcat	CVE-2021-44228	Dec 2021	Log4Shell
Logging library	Apache	Log4j	CVE-2021-44228	Dec 2021	Log4Shell
Enterprise Search Platform	Apache	Solr	CVE-2021-44228	Dec 2021	Log4Shell
Enterprise mobility management	MobileIron	Core Server	CVE-2021-44228	Dec 2021	Log4Shell
Data Stream	Apache	Flink	CVE-2021-44228	Dec 2021	Log4Shell
Virtualization	VMware	vCenter Server	CVE-2021-44228	Dec 2021	Log4Shell
Database	Apache	Druid	CVE-2021-44228	Dec 2021	Log4Shell
Database	Elastic	Elasticsearch	CVE-2021-44228	Dec 2021	Log4Shell
Hypervisor	ManageEngine	ServiceDesk, SupportCenter	CVE-2021-44077	Nov 2021	-
Monitoring solution	Grafana	Labs	CVE-2021-43798	Nov 2021	-
Webserver	Apache	Server	CVE-2021-41773	Oct 2021	-
Webserver	Apache	Server	CVE-2021-41773	Oct 2021	-
Webserver	Apache	Server	CVE-2021-42013	Oct 2021	-
Webserver	Apache	Server	CVE-2021-42013	Oct 2021	-
Webserver	Apache	Server	CVE-2021-40438	Sep 2021	-
Azure Cloud	Microsoft	Open Management Interface (OMI)	CVE-2021-38647	Sep 2021	OMIGOD
Virtualization	VMWare	vCenter Server	CVE-2021-22005	Sep 2021	-
Password Management	ManageEngine	ADSelfService Plus	CVE-2021-40539	Sep 2021	-
Email Server	Microsoft	Exchange Server	CVE-2021-41349	Sep 2021	-
Email Server	Microsoft	Exchange Server	CVE-2021-34473 CVE-2021-34523 CVE-2021-31207	Aug 2021	ProxyShell
Collaboration Software	Atlassian	Confluence	CVE-2021-26084	Aug 2021	-
Monitoring System	VisualTools	DVR	CVE-2021-42071	Jul 2021	-
Email Server	Microsoft	Exchange Server	CVE-2021-31195	May 2021	ProxyOracle
Virtualization	VMware	vCenter Server	CVE-2021-21985	May 2021	-
Virtualization	VMware	Workspace One	CVE-2022-22954	Apr 2021	-
Email Server	Microsoft	Exchange Server	CVE-2021-28480 CVE-2021-28481 CVE-2021-28482 CVE-2021-28483	Apr 2021	ProxyNotFound
Collaboration Software	GitLab	Server	CVE-2021-22205	Apr 2021	-
VPN Gateway	F5	BIG IP	CVE-2021-22986	Mar 2021	-
Email Server	Microsoft	Exchange Server	CVE-2021-26855 CVE-2021-27065	Mar 2021	ProxyLogon
Email Server	Microsoft	Exchange Server	CVE-2021-26855 CVE-2021-27065	Mar 2021	ProxyLogon Backdoor Webshells
Wordpress Plugin	Webnus	Modern Events Calendar Lite Server	CVE-2021-24146	Mar 2021	-
Cloud Management	VMWare	vRealize Operations Manager Server	CVE-2021-21975	Mar 2021	-
Planning System	Apache	OFBiz	CVE-2021-26295	Mar 2021	-
Webserver	Sebastian Hildebrandt	System Information Library for Node.JS	CVE-2021-21315	Feb 2021	-
Virtualization	VMware	vCenter Server	CVE-2021-21972	Feb 2021	-
Webserver	Node	Red	CVE-2021-3223	Jan 2021	-
Web Framework	Laravel	Laravel	CVE-2021-3129	Jan 2021	-
Web Framework	Apache	Struts	CVE-2020-17530	Dec 2020	-
Project management	Atlassian	Jira	CVE-2019-11581	Oct 2020	-
Web Framework	Oracle	Weblogic	CVE-2020-14882	Oct 2020	-
Web Framework	Oracle	Weblogic	CVE-2020-14883	Oct 2020	-
Networking product	Netgear	Router	CVE-2020-17409 CVE-2020-27866	Oct 2020	-
Monitoring System	Micro Focus	Operations Bridge Manager	CVE-2020-11853	Oct 2020	-
Firewall	Sophos	SG UTM	CVE-2020-25223	Sep 2020	-
Web Framework	Apache	Struts	CVE-2019-0230	Aug 2020	-
Firewall	Citrix	ADC/Gateway	CVE-2020-8193 CVE-2020-8195 CVE-2020-8196	Jul 2020	-
Firewall	Citrix	ADC/Gateway	CVE-2020-8194	Jul 2020	-
VPN Gateway	Cisco	ASA	CVE-2020-3187	Jul 2020	-
VPN Gateway	Cisco	ASA	CVE-2020-3452	Jul 2020	-
VPN Gateway	F5	BIG IP	CVE-2020-5902	Jun 2020	-
Webserver	Apache	Tomcat	CVE-2020-1938	Feb 2020	Ghostcat
Logging library	Apache	Log4j	CVE-2019-17571	Dec 2019	-
Firewall	Citrix	ADC	CVE-2019-19781	Dec 2019	-
Email service	Exim	Exim	CVE-2019-10149	Jul 2019	-
VPN Gateway	Fortinet	FortiGateway SSL VPN	CVE-2018-13379	May 2019	-
VPN Gateway	Pulse	Connect Secure	CVE-2019-11510	May 2019	-
Web Server	Adobe	Coldfusion	CVE-2018-15961	Sep 2018	-
Web Framework	Apache	Struts	CVE-2018-11776	Aug 2018	-
Web Server	Oracle	Weblogic	CVE-2018-2894	Jul 2018	-
CMS	Drupal	Drupal	CVE-2018-7600	Mar 2018	Drupalgeddon2
Webserver	Apache	Tomcat	CVE-2017-12617	Oct 2017	-
Web Framework	Apache	Struts	CVE-2017-12611	Sep 2017	-
Web Framework	Apache	Struts	CVE-2017-9791	Jul 2017	S2-048
Operating System	Microsoft	Windows	CVE-2017-0144	Mar 2017	EternalBlue
Utility	GNU Project	Bash	CVE-2014-6271	Sep 2014	Shellshock

How the OpenVAS scanner works

OpenVAS is a fork of the old Nessus scanner, performed in 2005 when Nessus became a commercial product. OpenVAS is currently developed and maintained by Greenbone Networks with support from the community.

OpenVAS implements each test in a plugin called NVT (Network Vulnerability Test). It has more than 57000 active plugins to detect a large number of vulnerabilities for many services and applications.

For example, here is how a simple NVT looks like. It's called fortigate_detect.nasl and shows if the target device is a Fortigate Firewall:

#
#  This script was written by David Maciejak
#  This script is released under the GNU GPL v2
#

if(description)
{
  script_id(17367);
  script_name("Fortinet Fortigate console management detection");
  script_family("General");
  script_dependencies("http_version.nasl");
  script_require_ports(443);
  exit(0);
}

#
# The script code starts here
#
include("http_func.inc");

function https_get(port, request)
{
  if(get_port_state(port))
  {

    soc = open_sock_tcp(port, transport:ENCAPS_SSLv23);
    if(soc)
    {
      send(socket:soc, data:string(request,"\r\n"));
      result = http_recv(socket:soc);
      close(soc);
      return(result);
    }
  }
}

port = 443;

if(get_port_state(port))
{
  req1 = http_get(item:"/system/console?version=1.5", port:port);
  req = https_get(request:req1, port:port);
  #<title>Fortigate Console Access</title>

  if("Fortigate Console Access" >< req)
  {
    security_note(port);
  }
}

OpenVAS Scanning Policy

While OpenVAS has multiple predefined policies, our scanner uses the one called Full and Fast. This one includes most of the NVTs and is updated to use the data collected by the previous plugins. For example, if a previous plugin detects the FTP service running on port 2121, it will run all the FTP-related plugins on that port. Otherwise, it won't.

Open Ports Detection

We've configured OpenVAS to scan for a default list of ports including the most common 6000 ports (TCP and UDP). However, keep in mind that the scanner first attempts to detect if the host is alive or not before doing the port scan. If the host is not alive (e.g. does not respond to ICMP requests) it shows zero open ports found.

Note: If the scanner does not find any open ports even though you know there are, we recommend you re-running the scan with the option "Check if the host is alive" disabled. This will skip host discovery and just start the port scan.

How long does an OpenVAS scan take?

Since the OpenVAS scanner performs a considerable number of tests, the full scan can take from 30 minutes to several hours. It mostly depends on the number of open ports found on the target host. If the number is bigger, the scanning time increases because OpenVAS runs a higher number of NVTs.
